Accessories
UTS : Your first choice in waterproof connectors !
Plastic protective cap
Part numbers
Shell
size Receptacle
cap
Plug cap
8500-5585A 8500-5594 8
8500-5586A 8500-5595 10
8500-5587A 8500-5596 12
8500-5588A 8500-5597 14
8500-5590A 8500-5599 18
Discrimination pin for size 16 cavities
In applications where similar connectors are used next to each other, mismatching can be
a reason for disturbances, system failure or even danger to operating personnel.
To eliminate mismatching, all TRIM TRIO
® connectors can be equipped with discrimination
keys, which offer unlimited possibilities for a «fool-proof» interconnection system.
When one of these discrimination keys is used, the TRIM TRIO ® connector will only mate
with a connector which has a vacant contact or discrimination cavity at the corresponding
position.
This system offers boundless opportunities for all applications which involve several
identical TRIM TRIO
® connectors.
The material used is Thermoplastic.
SMSPKE0
A dummy contact, which can be inserted
into an empty contact cavity in any of the
TRIM TRIO
® connectors.
14.0
2.0
4.0 Ø3.1
Colour coding rings
Part numbers
Shell
size
Receptacles Plugs
UTS710CCR* UTS610CCR* 10
UTS712CCR* UTS612CCR* 12
UTS714CCR* UTS614CCR* 14
Gasket
Part numbers /
neoprene
Shell size
UTFD11B 8
UTFD12B 10
UTFD13B 12
UTFD14B 14
UTFD16B 18
* Add G for Green, Y for Yellow, R for Red
For shell sizes 8 & 18, please consult factory
Bending protection spiral
Please consult factory.
