5
UTP Series
Dimensions
Note: all dimensions are in mm
Cable plug - UTP6
ØD ØC
B
B
Pin contact
Socket contact
ØA
Shell size ØA ±0.2
B max
ØC ±0.15 ØD ±0.15 ØE ±0.2
Pin contact Socket contact
10 26.7
31.8
23.9 / 26.75 10.9 12.2
19.1
12 31.4
23.9
13.8 15.1
14 34.5 17.0 18.3
16 37.8 19.9 21.5
18 40.8 31.8 / 33.0 23.9 / 29.0 22.4 24.0
20 43.9
31.8
24.9
25.6 27.2
22 47.0 28.5 30.4
24 50.1 26.2 31.7 33.5
Panel mounting - UTP0
ØD
ØG
ØC
A max E
F B max
Pin contact
Socket contact
Panel cut
ØJ
Shell size
A max
B ±0.15 C ±0.2 ØD ±0.15 ØE ±0.2 F ±0.25 ØG ±0.1 ØJ ±0.1
Pin contact Socket contact
10
31.7
24.3 / 27.6
2.3 11.3
15.0 18.3 23.8
3.2
15.1
12
24.3
19.0 20.6 26.2 18.2
14 22.2 23.0 28.6 21.4
16 25.3 24.6 31.0 24.6
18 31.7 / 34.0 24.3 / 30.4
2.5
11.3 / 17.9 28.5 27.0 33.3 27.7
20
33.3
27.0
14.5
31.7 29.4 36.5 30.9
22 28.0
3.5
34.9 31.8 39.7 34.1
24 30.4 15.3 38.0 34.9 42.9 3.9 37.3
