Ø 27
76,3
24 27 24
74,9
M 23 x 1
24 24
77,8
Ш 27
24
70,2
25
27
27
44
Ш 2,7
26,5
28,4
M 23 x 1
19,8
Ш 22
Ш 22,5 + 0,1
4 x holes Ø 2,7 mm (.11“) ..7.408.000.000
Flange 26 x 26 mm
Panel Connector, Male Thread, Front Mounting
Right Angle Connector, Female Thread , rotating
Straight Connector, Male Thread
Straight Female Connector
Panel hole
Dimensions and specifications may be changed without prior notice
Type Part Number
Cable-Ø Part Number
M 23 Fast Ethernet PoE Connectors / Housing
Cable-Ø Part Number
Inserts page 46 • Assembly instructions page 48
Inserts page 46 • Assembly instructions page 48
Inserts page 46 • Assembly instructions page 50
Inserts page 46 • Assembly instructions page 49
Cable-Ø Part Number
11-17 mm (.43 – .67“) ......7.108.600.000
11-17 mm (.43 – .67“) .......7.308.600.000
11-17 mm (.43 – .67“) .......7.208.600.000
