Installation murale, Wall installation – Nexera Allure Collection - Decorative Wall Panel (220530) User Manual
Page 3
3
03
H
H
WALL INSTALLATION
Installation murale
+
Not included / Pas inclus
12
305mm
12"
305mm
12"
G
Please note that the wall mounting plate H is designed
to be installed 12" (305mm) lower than the installation height
S.V.P. notez que la plaque de montage murale H doit être installée
12" (305mm) plus bas que la hauteur d’installation
Front view / Vue frontale
Side view / Vue de côté
Installation height
Hauteur d’installation
Installation height
Hauteur d’installation
Attach to the
wall with proper
anchor device
Attachez au mur
en utilisant une
