RCC130H-CRACK SAW
OPERATION AND PARTS MANUAL REV #1 (11/18/04)
PAGE 47
OPERATOR HANDLE ASSY.
OPERATOR HANDLE ASSY.
NO. PART
NO.
PART
NAME QTY. REMARKS
1 29022-017
HANDLE,
OPERATOR
1
2 29022-018
CRANK
SCREW
1
3 29020-030
KNOB
1
4
29020-031
SCREW, HEIGHT ADJUSTMENT
1
5 29022-019
BEARING
2
6
06503-012
SCREW, CAP ½-13 UNC X 1-1/2” PLATED GRD 5
4
7
08233-006
NUT, NYLOC 3/8”-16 UNC, PLATED
4
8
07594-024
PIN, ROLL 3/16” X 1-1/2”
1
9 29022-020
LEVER
1
10 29022-021
BUSHING
4
11 29022-022
HINGE
W/BELLEVILLE
2
12
29022-023
WASHER, BELLEVILLE 5/8”
2
13
08297-010
NUT, SELF-LOCKING 5/8-18 UNF, PLATED
1
14
07030-008
WASHER, FLAT ½”, PLATED
4
15
29022-024
SHAFT, OVER CENTER
1
16
06501-008
SCREW, CAP 3/8-16 UNC X 1,PLATED GRADE 5
4
17
29022-025
SCREW, CAP 3/8-16 UNC X 3-3/4” STAINLESS
1
18
07033-006
NUT, 3/8-16 UNC, PLATED
1
19 29022-026
TUBE,
BEARING
1
20
18982-010
NUT, 5/8-11 UNC,LH PLATED
2
21
14821-004
CLAMP, HOSE 1-4”
1
22 29020-034
BOOT,
RUBBER
1
23 29020-035
BARREL,
ADJUSTING
1
24
06922-004
NUT, JAM 5/8-18 UNF, LH PLATED
1
25
06505-048
SCREW, CAP 5/8-11 UNC X 6” PLATED, GRD 5
1
26
07033-010
NUT, HEXAGON 5/8-11 UNC, PLATED
1
27
07030-010
WASHER, FLAT 5/8” PLATED
2
28
29020-036
ROD END, MALE
1
29 29022-027
WASHER,
PLASTIC
2
30
29019-013
WASHER, FLAT 5/8” SPECIAL PLATED
1
31
08233-008
NUT, NYLOC ½-13 UNC, PLATED
4
32
CS8-0350
KILL SWITCH/ CABLE
1
34
CS8GH-0370
WIRE LOOM, SHUT-OFF
1
35
CS8-0390
T-TAP, 22-18 GUAGE WIRE
1
36 CV-0411
CLAMP,
PLATED
1
37
07029-008
WASHER, LOCK 1/4”
1
38
07030-008
WASHER FLAT 1/4”
1
39
06499-006
HHCS, 1/4”-20 X 3/4” UNC PLATED GRADE 5
1
