MP1 — OPERATION AND PARTS MANUAL — REV. #3 (03/29/10) — PAGE 45
TRAY ASSY.
TRAY ASSY.
NO.
PART NO. PART NAME QTY. REMARKS
1 29695-351 TRAY, WATER 1
2 0105 SCREW. HHC 5/16 - 18 X 1-1/2 1
3 29685-001 ARM, BLADE HEIGHT ADJST. 1
4 08233-005 NUT, LOCK 5/16 - 18 GRIPCO 1
5 23853-001 SNAP HOOK, SHOWER CURTAIN 2
6 23848-001 CURTAIN, SPLASH 1
7 23858-001 BOLT, WIRE EYE 1
8 1456 NUT, HEX FINISH 3/8 - 16 1
9 08233-006 NUT, LOCK 3/8 - 16 GRIPCO 1
10 29684-001 HOOK 2
11 10136 WASHER, FLAT 3/8 2
12 0166 A WASHER, LOCK 3/8 5
13 15503 KNOB, COMFORT GRIP 2
14 23783-001 WRENCH, HEX 3/4 1
15 2509 NUT, WING 1/4 - 20 PLTD 1
16 12391-004 WASHER, FLAT 1/4 AN970-4 1
17 23847-001 RUBBER STOPPER 1
18 0948 WASHER, FLAT SAE 1/4 1
19 5277 SCREW, HHC 1/4 - 20 X 1-1/2 1
20 1622 TIE, CABLE 1
21 29719-001 HANDLE LOCK 1
22 0447 WASHER, FLAT SAE 1/2 2
23 23843-001 WATER PUMP, ELECTRIC 1
24 26077-001 FITTING, BRASS 6 BARB 1/4FP 1
25 12694-001 HOSE CLAMP 2
26 23867-002 TUBING, VINYL 5/16 4 FT.
27 14233-002 Y-FITTING 1
