page 14 — CV seRIes VIbRatoR motoR • opeRatIon and paRts manual — ReV. #0 (04/30/13)
DiMensions
table 3. dimensions
Model
CV1A
CV2A
CV2B
CV3A
CV3B
Length
13.5 inches (343 mm)
13.5 inches (343 mm)
13.5 inches (343 mm)
Width
8.75 inches (222.25 mm)
8.75 inches (222.25 mm)
8.75 inches (222.25 mm)
Height
7.75 inches (196.85 mm)
7.75 inches (196.85 mm)
7.75 inches (196.85 mm)
Figure 1. Dimensions
W
L
H
