PAGE 16 — CA4HC WALK-BEHIND TROWEL— PARTS MANUAL — REV. #3 (11/14/07)
CA4HC TROWEL — GEARBOX ASSY.
GEARBOX ASSY.
1
2
3
7
8
8
4
1
2
3
4
5
6
6
7
7
9
10
11
16 17
18
18
19
19
20
21
22
13
13
23
25
26
28
14
15
8
3
2
1
4
5
6
TORQUE TO 15 FT-LBS (20 Nm)
APPLY SEALANT (LOCTITE
572 WHITE OR EQUIVALENT).
APPLY THREAD LOCK (LOCTITE
242 BLUE OR EQUIVALENT).
USE SPECIALLY FORMULATED
WHITEMAN GEARBOX LUBRICANT
P/N 10139 OR ISO OIL.
GEARBOX
REQUIRES 24 OZ. OF LUBRICATING
OIL FOR OPERATION
12
12
7
GEARBOX ASSEMBLY INCLUDES
ITEMS WITHIN DASHED LINE
EXCEPT ITEMS 12,13 AND 31
9
29
5
.
6 31
GEARBOX
OIL
22 OZ.
(751 mL)
GASKETS ARE NOT SOLD SEPARATELY.
SHIM (GASKETS) AS NECESSARY FOR
INPUT SHAFT END-PLAY.
GASKETS ARE NOT SOLD SEPARATELY.
SHIM (GASKETS) AS NECESSARY FOR
OUTPUT SHAFT END-PLAY.
7
GASKET AND SEAL KIT INCLUDES
ITEMS 1,4, 25, AND 29 PLUS GASKETS.
8
BEARING KIT INCLUDES ITEMS 6,7,18
AND 19.
33
32
34
36
34
35
PITCH CONTROL
CABLE
