PAGE 52 — B-SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #9 (07/06/10)

B-SERIES TROWEL — GEARBOX AND ENGINE MOUNTS ASSY.

GEARBOX AND ENGINE MOUNTS ASSY.

35

GEARBOX

OIL

22 0Z.

LUBRICATING

QTY. 1

GEARBOX REQUIRES
22 OZ. OF LUBRICATING
OIL FOR OPERATION.

1

USE SPECIALLY FORMULATED

WHITEMAN GEARBOX LUBRICANT

P/N 10139 OR ISO 680 OIL.

4

1

NOTES:

39

2

2

SEE GUARD RING ASSY., PAGE 60,

ITEM 1.

BEARING

KIT

38
