page 30 —sTxd6i RIde-ON TROWeL • paRTs maNuaL — Rev. #2 (1/23/13)
PIVOt assy.
TIGHTENING SEQUENCE
1
2
3
4
7
8
5
6
1
2
2
5
6
7
8
10
3
4
22
23
16
12
13
17
20
19
18
15
19
20
10
8
8
5
7
6
18
12
13
14
11
10
21
21
LEFT
RIGHT
BLUE
LOCTITE
24
3
1
2
APPLY BLUE LOCTITE #246 x 8 1
APPLY BLUE LOCTITE #246 x 12 2
APPLY MINIMAL AMOUNT OF LPS ANTI-SEIZE GREASE TO THREADS OF SCREW (ITEM 4).
HAND START SCREWS. FOLLOWING TIGHTENING SEQUENCE (SEE DIAGRAM ABOVE).
TORQUE SCREW ASSEMBLY (FIRST PASS) TO A VALUE OF 21 FT-LBS (28.47 N.m). FOLLOW
SAME SEQUENCE FOR FINAL TORQUE OF 41 FT-LBS (55.59 N.m).
CLEAN WITH NON-PETROLEUM BASE CLEANER BEFORE INSTALLING ITEMS 8 AND 10.
3
4
NOTES:
SEAL
KIT
25
