HTX-44K/Y RIDE-ON TROWEL— PARTS MANUAL — REV. #18 (08/28/12) — PAGE 59
HTX-44K/Y RIDE-ON TROWEL — RIGHT-HAND VALVE ASSY.
RIGHT-HAND VALVE ASSY. (KUBOTA/YANMAR - S/N 2000886 AND ABOVE)
NO. PART NO. PART NAME QTY. REMARKS
1# * $ 1318 TERMINAL, BULLET, FEMALE, 18-22 1
2# * $ 4692 TERMINAL, BULLET MALE 14-16 1
3# * $ 16083 NUT, HEX M12 P1.75 1
4 * $ 20155 PALM HANDLE, W/SWITCH, RIGHT .............................. 1 ........... INCLUDES ITEMS W/#
5 20165 PALM HANDLE KIT, L/R HANDLES W/O BOOT ............. 1 ........... INCLUDES ITEMS W/$
6 20829 VALVE ASSY., W/SWITCH ............................................. 1 ........... INCLUCES ITEMS W/ *
7 * 20832 VALVE, RH STEERING 1
8 * 20834 ADAPTOR, RH PALM HANDLE 1
9% * 21631 BOOT, STEERING VALVE 1
10 432233013 GUIDE PLATE KIT .......................................................... 1 ........... INCLUDES ITEMS W/%
11% BOOT, STEERING VALVE .............................................. 1 ........... SEE NOTE BELOW
12% NUT ................................................................................. 1 ........... SEE NOTE BELOW
13% GUIDE PLATE BUSHING ............................................... 1 ........... SEE NOTE BELOW
14% UPPER GUIDE PLATE ................................................... 1 ........... SEE NOTE BELOW
15 321800006 VALVE 4
16 421801100 SPRING, RETURN 4
17 430033036 LOWER GUIDE PLATE 1
NOTE ITEMS 12 THRU 14 CANNOT BE PURCHASED SEPARATELY
