BHN RIDE-ON POWER TROWEL — PARTS & OPERATION MANUAL — REV. #1 (10/17/02) — PAGE 29
STEERING ASSY. S/N L-41119 & ABOVE
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
0189
LEFT SIDE HAND GRIP .................................... 1 ............... NO OPTIONS
1
2267
LEFT SIDE HAND GRIP .................................... 1 ............... RETARDANT SPRAY OPT.
2
0189
RIGHT SIDE HAND GRIP
1
3
10130
HANDLE EXTENSIONS
2
4
11090
SHCS 3/8- 16 X 1.1/4”
1
5
2197
ACORN NUT 1/4- 20
2
6
0424
HHCS 1/4- 20 X 1.1/4”
2
7
11079
LOWER HANDLE
2
8
9154
HHCS 3/8- 16 X 1.3/4”
2
9
2196
SPACER
7
10
2063
SPHERICAL BEARING ..................................... 8 ............... RIGHT HAND MALE
11
1023
HHCS 3/8- 16 X 1.1/4”
8
12
0166A
LOCK WASHER 3/8”
2
13
2199
JAM NUT 3/8- 24
8
14
2064
SPHERICAL BEARING ..................................... 6 ............... RIGHT HAND FEMALE
15
10133
LOCK NUT 3/8- 16
8
16
0183
COTTER PIN
4
17
11073
PIN
2
18
11072
BEARING
4
19
11071
STEERING CONTROL LEVER
2
20
11082
CAP
4
21
10605
LEFT SIDE STEERING ASM.
1
22
8151
FLAT WASHER 3/4”
2
23
10603
BOSS & SUPPORT
2
24
10606
RIGHT SIDE STEERING ASM.
1
25
5283
LOCK NUT 5/16- 18
8
26
0655
HHCS 5/16- 18 X 3/4”
10
27
11089
SHCS 3/8- 16 X 1.3/4”
1
28
0161C
LOCK WASHER 5/16”
2
29
11087
LINKAGE ROD
1
30
0300B
FLAT WASHER 5/16”
2
31
2080
RIGHT/ LEFT MOTION SHAFT
1
32
10718
RIGHT/ LEFT MOTION ARM
1
33
5228
GREASE FITTING
7
34
2188
SPACER
2
35
2193
ADAPTER PLATE PIN
1
36
1162A
LUBRA- CAP
5
37
2219
COTTER PIN
2
38
2168
BUSHING
4
39
0300B
FLAT WASHER 5/16”
2
S.N. LH41119 AND ABOVE
