PAGE 4 — DSGPULW DUOSCREED — OPERATION AND PARTS MANUAL — REV. #6 (12/10/10)
l
DSGPULW DUOSCREED —TABLE OF CONTENTS
Specification and part
number are subject to
change without notice .
Honda GX35SAT Engine
Air Cleaner Assembly .........................................38-39
Cam Pulley Assembly ........................................40-41
Carburetor Assembly .........................................42-43
Crankcase Assembly .........................................44-45
Crankshaft and Piston Assembly ......................46-47
Fan Cover and Clutch/Assembly........................48-49
Recoil Starter Assembly.....................................50-51
Flywheel and Ignition Coil Assembly .................52-53
Fuel Tank ............................................................54-55
Muffler Assembly ...............................................56-57
Engine Top Cover Assembly .............................. 58-59
Labels ................................................................60-61
Terms and Conditions Of Sale — Parts .................. 62
Multiquip DS-Series —
Vibratory DuoScreed
Here's How To Get Help ............................................ 3
Table Of Contents ..................................................... 4
Parts Ordering Procedures ....................................... 5
Rules For Safe Operation ...................................... 8-9
Operation and Safety Decals .................................. 10
Specifications .......................................................... 11
General Information ................................................ 12
Components (DuoScreed) ...................................... 13
Components (Honda GX35SAT Engine) ................. 14
Assembly Instructions ........................................ 15-17
Starting ................................................................... 18
Application/Operation ......................................... 19-22
Maintenance ...................................................... 23-24
Troubleshooting (DuoScreed) ................................. 25
Troubleshooting (Honds GX35SAT Engine) ............ 26
Explanation Of Codes In Remarks Column ............ 28
Suggested Spare Parts ........................................... 29
Nameplate and Decals....................................... 30-31
Main Assembly ................................................... 32-35
Blade Assembly ................................................. 36-37
NOTE
