WM120PH/SH HYDRAULIC MIXER • OPERATION AND PARTS MANUAL — REV. #7 (09/15/11) — PAGE 63
S/N KA26943 TO GE 210000
JANUARY 1996 TO MAY 2000
NO PART NO PART NAME QTY. REMARK
1 13221 ENGINE COVER ASSY. - PLASTIC ONLY ........ 1 ........... S/N KA26943 TO GE210000
2 3089 HINGE PIN 1
3 8151 FLAT WASHER 3/4" 2
4 0183 COTTER PIN 2
5 3163 SMALL HINGE PLATE 3
6 3162 LARGE HINGE PLATE 1
7 10024 LOCK NUT 1/4-20 11
8 3164 FHSCS 1/4-20 X 1" 6
9 0948 LOCK WASHER 1/4" 10
10 491010 SHROUD FASTENER ASSY. ............................ 4 ........... REPLACES 929025
......................................................................................... INCLUDES ITEMS W/ *
11 * COTTER PIN 4
12 * CLEVIS PIN 4
13 0131A HHCS 1/4-20 X 3/4" 10
14 3401 SHROUD BRACE 1
15 13287 LOCK NUT 8-32 8
16 1307 RHMS 8-32 X 1/2" 8
17 2203 FLAT WASHER #10 4
PLASTIC ENGINE COVER ASSY.
