ST-2005 SERIES SUBMERSIBLE PUMPS — OPERATION & PARTS MANUAL — REV. #3 (09/21/04) — PAGE 21
Figure 12. Pump Performance Curves
ST-2005 SERIES SUB. PUMP — PERFORMANCE CURVES
0 30 60 90
ST-2005T Performance Curve
Capacity(US.G.P.M)
T o
ta
l Head
(Feet) 60
40
20
TOTAL HEAD
CAPACITY
Max 34 FT
Max 72 G.P.M
0
30 60 90
ST-2005C Performance Curve
Capacity(US.G.P.M)
To
ta
lHead
(Feet) 60
40
20
TOTAL HEAD
CAPACITY
Max 42 FT
Max 85 G.P.M
0 30 60 90
ST-2005S Performance Curve
Capacity(US.G.P.M)
T o
ta
l Head
(Feet) 60
40
20
TOTAL HEAD
CAPACITY
Max 36 FT
Max 70 G.P.M
0 30 60 90
ST-2005CUL Performance Curve
Capacity(US.G.P.M)
60
40
20
TOTAL HEAD
CAPACITY
Max 42 FT
Max 85 G.P.M
