PAGE 8 — YELLOW SUBMARINE PUMP — OPERATION AND PARTS MANUAL — REV. #1 (03/22/10)
SPECIFICATIONS
1. Motor Rotation – Upon start-up, the pump "kicks" in the opposite direction of motor rotation. The correct rotation is
counterclockwise (CCW) as viewed from the impeller end of the pump.
Table 1. Specifications
Model Yellow Submarine
Type Submersible Pump
Impeller Plastic
Suction & Discharge Size 1.25 in. (31.75 mm)
Maximum Pumping Capacity
33 gallons/minute
(125 liters/minute)
Discharge Height
Above Pumping Level
5 ft (1.5 meters) 1,800 gallons/hr (6,814 liters)
10 ft (3.0 meters) 1,320 gallons/hr (4,997 liters)
15 ft (4.5 meters) 720 gallons/hr (2,725 liters)
20 ft (6.0 meters) 120 gallons/hr (454 liters)
Power 0.25 HP (0.37kw)
Voltage Phase 1Ø 115V
Starting Amps 11.5
Running Amps 2.3
Thermal Overlaod Protection YES
Rotation CCW
Power Cable Length 9.0 ft. (274 cm.)
Dimensions (Dia x Height) 6-1/4 in. (15.9 cm.) x 9.5 in. (24 cm.)
Dry Net Weight (Shipping) 8.5 lbs. (3.85 Kg.)
Dry Net Weight 6.0 lbs. 2.72 Kg.)
