PAGE 16 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
CAUTION :
DO NOT attempt to start the engine unless
the pump has previously been
primed with
water. Severe pump damage will occur if
pump has not been primed.
Engine Oil
1. Make sure pump/engine is on level ground.
2. Pull the engine oil dipstick (Figure 3) from its holder.
Figure 3. Dipstick Location
3. Verify that oil level (Figure 4) is maintained between the
two notches on the dipstick.
MQ41TDH — INITIAL START-UP (ENGINE)
4. If engine oil is low, fill engine crankcase with lubricating
oil through filler hole (Figure 3), but do not overfill.
5. The oil listed in Table 3 is recommended to ensure better
engine performance. Use class CD or higher grade motor
oil.
Figure 4. Engine Oil Dipstick
Table 3. Oil Selection Chart
HOLDER
ENGINE OIL
DIPSTICK
-40
-30
-10
-20
-22
-40
-4
-14
0 32
50
68
86
104
122
10
20
30
40
50
F C
5W/30
5W/40
10W
10W/30 10W/40 15W/40
20W/20
30
40
OIL: SAE
