QP4TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #3 (01/29/14) — PAGE 31
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
14660600100002 CASING
1
2
14660600200002 CASING COVER....................................................1............OCTOBER 2007 AND BELOW
2
14660600210002 CASING COVER....................................................1............NOVEMBER 2007 AND ABOVE
3
14660000900002 SUCTION COVER, NPT 4"
1
4
14660000900002 DELIVERY COVER, NPT 4"
2
5
14660601700002 DRAIN COVER
1
6
12471002500002 DRAIN COVER SET HANDLE
2
7
1466040031ASSY IMPELLER ASSEMBLY
1
8
1466000130
VOLUTE CASING
1
9
1466040700
WEAR PLATE
1
10
14660002200002 DRAIN SET HANDLE
4
11*
0482200240
O-RING (MECHANICAL SEAL SLEEVE)
2
12
0641400430
SPLIT PIN
4
13
0131190820
CAP SCREW, M8X20 (VOLUTE CASING)
3
14
1401350350
CHECK VALVE
1
15
0105051045
BOLT, M10X45 (ENGINE)
4
16*
0483602750
O-RING (DRAIN COVER)
1
17
1466330460
O-RING (CASING)
1
18
1466214010P002 BASE
1
19
1401330360
DELIVERY COVER PACKING
2
20
0451290080
WASHER, LOCK M8 ( WEAR PLATE )
3
21
14662140210014 ENGINE BASE .......................................................1............REPLACES 14662140200014
22
0631211159
FLOODING CAP, PF1 1/2"
1
23
0631211159
DRAIN CAP, PF1 1/2"
2
24*
0803442930
MECHANICAL SEAL
1
25*
0811885433
MECHANICAL SEAL SLEEVE
1
26*
0852834525
ADJUST LINER, F45XF25.4 T0.3
1
27*
0852854525
ADJUST LINER, F45XF25.4 T0.5
1
28
0131290665
CAP SCREW, 3/8-16UNC×65
(CASING CVR SET BOLT)
4
29
0141050825
SCREW, M8×25 (DRAIN CUVER SET HANDLE)
4
30
0131151225
CAP SCREW, M12×25 (SUCTION COVER
4
31
0131190820
CAP SCREW, M8×20 (WEAR PLATE)
3
32
0131151230
CAP SCREW, M12×30 (CASING)
6
33
0105051040
BOLT, M10×40 (PUMP)
2
34
0520040440
KEY, 6.3×40
1
35
0723302546
CUSHION RUBBER
4
36
0458220071
WASHER, SEAL (IMPELLER)
1
37
0107090650
BOLT, 3/8-24UNFX50 (IMPELLER)
1
38
1466200270
HINGE BOLT, M10×65
4
39
1466220280
HINGE PIN
4
PUMP ASSEMBLY
