QP3TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #8 (01/29/14) — PAGE 31
NO.
PART NO.
PART NAME
QTY.
REMARKS
1 1992100011 CASING
1
2
1992100020
CASING COVER
1
3
13910001600014 SUCTION COVER
1
4
1992100173
DRAIN COVER ......................................................1............REPLACES P/N 1992100171
5
19920002200014 DRAIN COVER HANDLE
4
6
1992040033ASSY IMPELLER KIT .......................................................1............INCLUDES ITEMS W/#
7
1992000110
VOLUTE CASING ..................................................1............REPLACES P/N 1992000133
8
1992100742
SUCTION PLATE
1
9
1247100250
DRAIN COVER SET HANDLE
2
10
1992330410
SUCTION PLATE PACKING
1
11
1992250700
WEAR PLATE
1
12
0105090820
BOLT(CASING COVER), M8 X 20
4
13
07904330300014 NIPPLE, NPS3" X NPT3"
2
14
1378350350
CHECK VALVE
1
15
0105091045
BOLT (ENGINE), M10 X45
4
16
43130006000014 CASING COVER PLATE
1
17@ 0483602250
O-RING (DRAIN COVER)
1
18
0489403400
O-RING (CASING), 4 X 340 MM
1
19
1992214010P002 BASE, SS400
1
20
0481310800
O-RING (NIPPLE)
2
21#@ 0482200240
O-RING, IMPELLER, MECH SEAL .......................2............SEE NOTE BELOW
22
19922140200014 ENGINE BASE, SS400
1
23
0631211159
FLOODING CAP, PF1-1/2"
1
24
0631211159
DRAIN CAP, PF1-1/2"
1
25@ 0803442930
MECHANICAL SEAL
1
26@ 0811885446
MECHANICAL SEAL SLEEVE, DIA. 30MM
1
27@ 0852834525
ADJUST LINER DIA. 45 X 25.4 MM TO.3
1
27-1@ 0852854525
ADJUST LINER DIA. 45 X 25.4 MM T0.5
1
28
0191170625
BOLT(IMPELLER), 3/8 X16 UNF X 25
4
29
0131190823
SCREW (VOLUTE CASING) M8 X 22 ...................4............REPLACES P/N 0141090820
30
0141090825
SCREW (DRAIN CVR. SET HANDLE) M8 X 25 4
31
0131191290
CAP SCREW (CASING), M12 X 90
1
32
0131191235
CAP SCREW (CASING), M12 X 35
4
33
0105091040
BOLT (PUMP), M10 X 40
2
34
0459220120
SEAL WASHER (CASING) M12
1
35
0723302040
CUSHION RUBBER, 40 X 20 M10
4
36#
0458220100
SEAL WASHER, IMPELLER
1
37#
0191190750
BOLT IMPELLER
1
PUMP ASSEMBLY
NOTICE
Item 21, o-ring, is included in impeller kit, item 6. When
ordered as part of the kit, quantity of o-ring is one.
Replacement of impeller requires two o-rings, so it is
necessary to order one additional o-ring.
