QP3TE TRASH PUMP — OPERATION AND PARTS MANUAL— REV. #4 (11/15/10) — PAGE 31
QP3TE — PUMP ASSY.
PUMP ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 1992100011 CASING 1
2 1992100020 CASING COVER 1
3 13910001600014 SUCTION COVER 1
4 1992100173 DRAIN COVER .......................................................... 1 ........... REPLACES P/N 1992100171
5 19920002200014 DRAIN COVER HANDLE 4
6 1992040033ASSY IMPELLER KIT ........................................................... 1 ........... INCLUDES ITEMS W/#
7 1992000110 VOLUTE CASING ...................................................... 1 ........... REPLACES P/N 1992000133
8 1992100742 SUCTION PLATE 1
9 1247100250 DRAIN COVER SET HANDLE 2
10 1992330410 SUCTION PLATE PACKING 1
11 1992250700 WEAR PLATE 1
12 0105090820 BOLT(CASING COVER), 5/16-24UNF X 25 4
13 07904330300014 NIPPLE, NPS2" X NPT2" 2
14 1378350350 CHECK VALVE, NBR+SS400 1
15 0105091045 BOLT(ENGINE), M8 X 40 4
16 43130006000014 CASING COVER SET PLATE 1
17@ 0483602250 O’RING (DRAIN COVER), G195 1
18@ 0489403400 O’RING (CASING), 1
19 1992214010P002 BASE, SS400 1
20 0481310800 O-RING (NIPPLE), G55 2
21@# 0482200240 O-RING, IMPELLER, MECH SEAL ............................ 2 ........... SEE NOTE BELOW
22 19922140200014 ENGINE BASE,SS400 1
23 0631211159 FLOODING CAP, PF1 1/2" 1
24 0631211159 DRAIN CAP, PF1 1/2" 1
25@ 0803442930 MECHANICAL SEAL, EH791-030-T, SIC X SIC 1
26@ 0811885446 MECHANICAL SEAL SLEEVE, DIA. 25MM 1
27@ 0852834525 ADJUST LINER, 45 X25.4 MM T0.3 1
27-1@ 0852854525 ADJUST LINER,45 X 25.4 MM T0.5 1
28 0191170625 BOLT, CASING COVER SET PLATE 4
29 0131190823 CAP SCREW (VOLUTE CASING), M8 X 20 .............. 4 ........... REPLACES P/N 0141090820
30 0141090825 SCREW (DRAIN COVER SET HANDLE), 4
M8 X 25
31 0131191290 CAP SCREW (CASING), M12 X 70 1
32 0131191235 CAP SCREW (CASING), M12 X 35 4
33 0105091040 BOLT (PUMP), M10 X 40 2
34 0459220120 SEAL WASHER(CASING), M12, W12S1 1
35 0723302040 CUSHION RUBBER, 40 X 20 MM M10 4
36# 0458220100 SEAL WASHER, IMPELLER 1
37# 0191190750 BOLT, IMPELLER 1
ITEM 21, O-RING, IS INCLUDED IN IMPELLER KIT, ITEM 6. WHEN
ORDERED AS PART OF THE KIT, QUANTITY OF O-RING IS ONE.
REPLACEMENT OF IMPELLER REQUIRES TWO O-RINGS, SO IT
IS NECESSARY TO ORDER ONE ADDITIONAL O-RING.
