PAGE 12 — QP2H CENTRIFUGAL PUMP • OPERATION AND PARTS MANUAL — REV. #1 (01/29/14)
SPECIFICATIONS (ENGINE)
Table 2. Specifications (Engines)
Engine
Model HONDA GX120UT2PX2
Type
Air-cooled 4 stroke, Single
Cylinder, OHV,
Horizontal Shaft Gasoline
Engine
Bore x Stroke
2.40 in. x 1.60 in.
(60 mm x 42 mm)
Displacement 118 cc (7.3 cu-in)
Max Output 4.0 H.P./3,600 R.P.M.
Fuel Tank Capacity
Approx. 0.53 U.S. Gallons
(2.0 Liters)
Fuel Unleaded Automobile Gasoline
Lube Oil Capacity 0.59 quarts (0.56 liters)
Speed Control Method Centrifugal Fly-weight Type
Starting Method Recoil Start
Dimension
(L x W x H) 11.7 x 13.4 x 12.5 in.
(297 x 341 x 318 mm)
Dry Net Weight 28.7 lbs (13 Kg.)
Figure 2. QP2H Performance Curve
3.3 FT
23.3 FT
16.7 FT
10 FT
