MVH508DZ PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (04/04/14)— PAGE 11
SPECIFICATIONS
Table 1. MVH508DZ Specifications
Centrifugal Force 14613 lbf (65 kN)
Vibration Frequency 4,150 vpm (70 Hz)
Maximum Traveling Speed 82 ft/min (25 m/min)
Plate Size (W x L) 25.59 x 35.43 in (650 x 900 mm)
Plate Size (W x L) with extension plates 31.5 x 35.43 in (800 x 900 mm)
Max. Forward Speed 82 ft./min (25 m/min)
Operating Weight 1157.42 lbs. (525 kg.)
Operating Weight with extension plates 1181.68 lbs. (536 kg.)
Table 2. Engine Specifications
Engine Make HATZ
Engine Model 1D81S-325
Engine Type Air-cooled, 4 Cycle Diesel Engine
Cylinder Bore X Stroke 3.94 in. x 3.35 in. (100 mm x 85 mm)
Displacement 40.7 cu-in (0.667 l)
Maximum Ouput 11.9 BHP (8.9 kW) @ 2500 RPM
Fuel Type Diesel
Oil Capacity 2 qts (1.9 liters)
Starting Method Recoil/Electric Start
Weight (Recoil Start) 213.8 lbs (97 Kg.)
Weight (Electric Start) 231.4 lbs (105 Kg.)
