MVH308GH PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #0 (02/28/14)— PAGE 71
HONDA GX270UT2SMXC ENGINE — AIR CLEANER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 16271ZE2010 PACKING, ELBOW 1
2 17210ZE3505 AIR CLEANER ELEMENT ................................1................INCLUDES ITEMS W/ #
3# 17218ZE3505 FILTER, OUTER 1
4$ 17219ZE3840 PACKING, AIR CLEANER COVER 1
5 17230ZE3841 COVER CP, AIR CLEANER (CYCL) 1
6# 17232891000 GROMMET, AIR CLEANER 1
7$ 17238ZE2310 COLLAR, AIR CLEANER 2
8$ 17239ZE3840 COLLAR B, AIR CLEANER 1
9 17410ZE3841 ELBOW CP, AIR CLEANER ..............................1................INCLUDES ITEMS W/ $
10 17470ZE3842 CASE CP, PRE-AIR CLEANER 1
11 17475ZE3841 CAP, PRE-AIR CLEANER 1
12 17476ZE3841 GUIDE, PRE-AIR CLEANER 1
13 90009Z1C000 BOLT, WASHER 6X22 1
14 90142MB0000 SCREW, PAN 5X16.5 5
15 90325044000 NUT, TOOL BOX SETTING 2
16 9405006000 FLANGE NUT 6MM 2
