Hydraulic system assy – Multiquip MVH502DSB2 User Manual
Page 41
MVH502DSB/DSB2 PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #5 (03/11/11) — PAGE 41
NO.
PART NO.
PART NAME
QTY.
REMARKS
51
456337780
SELECTOR VALVE
1
52
001220615
BOLT 6X15 T
4
53
030206150
WASHER, LOCK M6
4
54
031106100
WASHER, FLAT M6
4
55
457446180
OIL HOSE 1370L
1
56
457446190
OIL HOSE 1150L
1
57
457451750
OIL HOSE IB105- L820
1
58
457446210
OIL HOSE 1100L
1
59
955404271
SPIRAL TUBE, SR15- 850L
2
60
954403060
CLAMP HC- 40
1
61
954403070
CLAMP SPACER HC- 40
1
62
001220612
BOLT 6X12 T
2
63
030206150
WASHER, LOCK M6
2
64
506010070
CLAMP TC-150
1
65
954001160
ELBOW 90 PT1/4- PF1/4
4
66
457112910
OIL TANK
1
67
001221030
BOLT 10X30 T
2
68
030210250
WASHER, LOCK M10
3
69
031110160
WASHER, FLAT M10
3
70
505015380
PLUG PT 1/4
1
71
457332440
COVER, OIL TANK
1
72
457445870
PACKING, OIL TANK
1
73
001220820
BOLT 8X20 T
2
74
030208200
WASHER, LOCK M8
2
75
031108160
WASHER, FLAT M8
2
76
456449280
FILTER OIL TANK
1
77
457445861
JOINT 80L
1
79
506010060
CLAMP TC- 350
2
80
457448680
BREATHER PLUG
1
81
05340020
PACKING 19302
2
82
457448380
BREATHER CAP
1
83
457451740
BREATHER JOINT
1
84
551010630
ELBOW PT1/4- PF3/8 1034- 06
1
86
953405260
PACKING 1/4 ( CU )
3
87
605010360
BUSHING 3/8X1/4
1
88
457446820
COVER BRACKET
1
89
001221035
BOLT 10X35 T
1
90
955404276
SPIRAL TUBE 11D- 250L ............................. 1 ...... G1185-
HYDRAULIC SYSTEM ASSY.
