PAGE 10 — MVH-406DSY PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (08/13/07)

MVH-406DSY — OPERATION AND SAFETY DECALS

Figure 2. Operation and Safety Decals

Figure 2 displays the operation and safety decals as they appear on the reversible plate compactor. Should any of these decals
become damaged or unreadable, contact the Multiquip Parts Department for a replacement set.

P/N 920211640

Shell Tellus Oil

P/N 920211090

P/N 920204580

P/N 920201580

MVH-406

OPERATIONAL CAUTION

Do not move travel lever

if engine stops

NPA-1106

DCL333

P/N 920203330

P/N 920106760

STOP

RUN

START

V BELT HDPF-5370

P/N 920211010

NPA-537 J

SAE 10W-30
MOTOR OIL

P/N 920201950

NPA-195 J

P/N: 920209620

0PERATIONAL CAUTION

Prior to OPERATION, check the engine oil and fuel levels. If not enough, add to proper levels.

Warm up engine at low speed for 3-5 minutes.

Operate machine at full throttle speed. (incorrect clutch engagement causes clutch to burn.)

Use travel lever for forward & reverse motion. Do not push or pull travel lever strongly.

NPA-962 J

P/N 920105070

Serial No.
Model No.

CONTACT

MQ PARTS DEPT.

P/N 920211060
