V304 VIBRATORY ROLLER — OPERATION AND PARTS MANUAL — REV. #8 (11/13/09) — PAGE 21
Gasoline Check
1. Remove the gasoline cap located on top of fuel tank.
2. Handle Fuel in a safety container. If the container does not
have a spout use a funnel.
3. Visually inspect to see if fuel level is low. If fuel is low,
replenish with unleaded fuel. When refueling, be sure to use
a strainer for filtration. DO NOT top-off fuel. Wipe up any
spilled fuel.
4. Pay attention to the fuel tank capacity when replenishing
fuel. Refer to the fuel tank capacity listed on page 11,
Engine Specification Table 1.
Explosive Fuel
V304 — INSPECTION
Water Tank
1. Fill the water tank (Figure 13) with clean water, and verify
that valve for the water tank is closed .
Figure 12. Fuel Tank Filler Port
Figure 13. Water Tank Filler Port
Hydraulic Pump Fluid
1. Visually inspect the hydraulic fluid in the hydraulic reservoir
(Figure 14). If the hydraulic fluid is low, fill the reservoir with
Mobil 300, GM Dextron B or Ford MZC-41A type hydraulic
transmission fluid to the correct level. The correct hydraulic
fluid level will be indicated on the reservoir.
Figure 14. Hydraulic Reservoir Filler Port
