PAGE 16 — MT-60H/H2 — PARTS & OPERATION MANUAL — REV. #12 (05/29/07)
Operation
1. To start the rammer tamping action, move the throttle lever
(Figure 9) quickly from IDLE (close) to the FULL OPEN
position . DO NOT move the throttle lever slowly as this may
cause damage to the clutch or spring.
Figure 9. Throttle Lever
3. To stop the tamping action, move throttle lever quickly from
the FULL OPEN to IDLE position.
Stopping The Engine
Normal Shutdown
1. Move throttle lever quickly from the FULL OPEN to IDLE
position (Figure 9) and run the engine for three minutes at
low speed. After the engine
cools , turn the engine start/stop
switch to the “STOP” position (Figure 6) until engine comes
to a complete stop.
2. Close the fuel shut- off valve by moving the fuel cock lever to
the CLOSED position. See Figure 5.
Emergency Showdown
1. Move the throttle lever quickly to the IDLE position, and turn
the engine start/stop switch to the STOP position.
MT-60H/H2 — OPERATION
2. The MT-60H/H2 Tamping rammer is designed to run at 5,500
rpm. At optimum rpm the foot hits at the rate of 675 impacts
per minute. Increasing throttle speed past factory set rpm
does not increase impacts and may damage unit. The MT-
60H/H2 is designed to advance while tamping. For faster
advance, pull back slightly on the handle so that rear of foot
contacts soil first.
Make sure that the throttle lever is moved to the FULL OPEN
position. Operating the rammer at less than full speeds can
result in damage to the clutch springs or foot
CAUTION CAUTION CAUTION CAUTION CAUTION
