CARBURETOR AND OIL PUMP ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
210
1616230100
CARBURETOR ASSY ............... 1 ............... INCLS. ITEMS W/# REPLACES 1616230140
210-1#
1616253508
THROTTLE VALVE
1
210-3#
5806083310
CHOKE VALVE ........................... 1 ............... REPLACES 161625208
210-4#
2376245108
SCREW
1
210-5#
2076242008
PILOT JET
1
210-6#
*
1616235408
ADJUSTER
1
210-7#
*
2306244608
SPRING
1
210-8#
1616252008
SHAFT ASSY (CHOKE) ............ 1 ............... REPLACES 1616252038
210-10#
*
2246245208
SCREW MC-0414
1
210-11#
1616253080
SHAFT ASSY (THROTTLE)
1
210-12#
1616235108
BOLT
1
210-14#
*
5806083400
NEEDLE ..................................... 1 ............... REPLACES 1616235208
210-15#
2146251508
FLOAT PIN
1
210-16#
1616235008
FLOAT BODY
1
210-17#
*
2366245008
PACKING 826-08003
1
210-18#
*
2366254008
PACKING 826-42001
1
210-19#
2366250508
FLOAT 859-14004
1
210-20#
1616244008
MAIN NOZZLE
1
210-22#
*
2266240008
MAIN JET
1
210-26#
1616235308
HOSE
1
210-28#
2366235008
SCREW
1
210-41#
*
2066244608
SPRING
1
210-44#
*
1616240008
MAIN JET
1
210-82#
*
2366244508
SPRING 730-03012
1
210-104#
*
2366254108
PACKING
1
700
1616390110
OIL PUMP ASSY ........................ 1 ............... REPLACES 1616390100
710
0011406250
BOLT AND WASHER ASSY
2
715
0565220011
CLIP
1
720
1616350101
COLLAR CP (OIL INJ.)
1
725
*
1573500103
GASKET, INSULATOR
1
*
KITCARBEC12HS
KIT,CARBURETOR EC12HS .... 1 ............... INCLUDES ITEMS W/
*
ROBIN EC12HS ENGINE — CARBURETOR ASSY.
