MT-60HS — PARTS & OPERATION MANUAL — REV. #7 (03/02/01) — PAGE 15

Stopping The Engine

Normal Shutdown

1. Move throttle lever quickly from the

FULL OPEN

IDLE

position (Figure 10) and run the engine for three minutes at
low speed. After the engine

cools

, turn the engine

start/stop

switch to the “

OFF

” position (Figure 5) until engine comes

to a complete stop.

2. Close the fuel shut- off valve by moving the fuel cock lever to

the

CLOSED

position. See Figure 5

Emergency Showdown

1. Move the throttle lever quickly to the

IDLE

position, and turn

the engine start/stop switch (Figure 6) to the

STOP

position.

MT-60HS — OPERATION

CAUTION:

Make sure that the throttle lever is moved to the

FULL OPEN

position (Figure 9). Operating the

rammer at less than full speeds can result in
damage to the clutch springs or foot

Figure 9. Throttle Lever

2. The MT-60HS Tamping rammer is designed to run at 5,500

rpm. At optimum rpm the foot hits at the rate of 675 impacts
per minute. Increasing throttle speed past factory set rpm
does not increase impacts and may damage unit. The MT-
60HS is designed to advance while tamping. For faster
advance, pull back slightly on the handle so that rear of foot
contacts soil first.

If the carburetor is flooded or the crankcase is loaded with
excess fuel, open the drain plug as shown in (Figure 8) and
drain out excess fuel.

Figure 8. Drain Plug

Operation

1. To start the rammer tamping action, move the throttle lever

(Figure 10) quickly from

IDLE

(close) to the

FULL OPEN

position .

DO NOT

move the throttle lever slowly as this may

cause damage to the clutch or spring.
