page 10 — MTX80SD RaMMeR • opeRaTion anD paRTS Manual — Rev. #0 (07/20/12)
speCifiCatiOns
Table 1. Rammer Specifications
Overall Height 39.37 in. (1000 mm)
Overall Width 13.89 in. (353 mm)
Over Length 30.78 in. (782 mm)
Shoe Size (W x L) 13.4 x 11.2 in. (340 x 285 mm)
Fuel Tank Capacity 2.7 qt. (2.5 liters)
Lubrication Oil Capacity 0.9 qt. (0.82 liter)
No. of Impacts Per Second 10.7 - 11.3
Impact Force 3,713 lbf (16.5 kN)
Impact Plate Stroke 2 - 3.15 in. (50 - 80 mm)
Operating Weight 181 lbs. (82 kg)
Measured Sound Power Level 105 dB
Guaranteed Sound Power Level 107 dB
Max. Sound Pressure Level 95 dB
Table 2. engine Specifications
Model Robin ER120D45000 Engine
Type
Air-Cooled 4 Stroke, Overhead camshaft,
single cylinder gasoline engine
Piston Displacement 7.4 cu.in. (121 cc)
Max. Output 3.5 hp/3,600 rpm (2.6 KW)
Cooling System Air-Cooled
Engine Oil Capacity 0.4 qt. (0.35 liters)
Fuel Unleaded gasoline
Lubricant for Engine Automobile Oil; Class SE or higher
Starting System Recoil Starter
Spark Plug Type NGK CR5HSB
