page 10 — MTX70HF RaMMeR • opeRaTion and paRTs Manual — Rev. #0 (03/08/12)
speCiFiCatiOns
Table 1. Rammer specifications
Overall Height 40.04 in. (1017 mm)
Overall Width 13.78 in. (350 mm)
Over Length 28.1 in. (713 mm)
Shoe Size (W x L) 13.4 x 11.2 in. (340 x 285 mm)
Fuel Tank Capacity 2.1 qt. (2 liters)
Lubrication Oil Capacity 0.86 qt. (0.82 liter)
No. of Impacts Per Second 10.7 - 11.5
Impact Force 2,855 lbf (12.7 kN)
Impact Plate Stroke 2 - 3.2 in. (50 - 80 mm)
Operating Weight 163.13 lbs. (74 kg)
Measured Sound Power Level 104 dB
Guaranteed Sound Power Level 107 dB
Max. Sound Pressure Level 94 dB
Table 2. engine specifications
Model Honda GX100UKRB5 Engine
Type
Air-Cooled 4 Stroke, Overhead camshaft,
single cylinder gasoline engine
Piston Displacement 6.0 cu.in. (98 cc)
Max. Output 3.0 hp/3,600 rpm (2.2 KW)
Max. Governed Speed, No Load 3,800 - 4,100 rpm
Cooling System Air-Cooled
Engine Oil Capacity 0.3 qt. (0.28 liters)
Fuel Unleaded gasoline
Lubricant for Engine Automobile Oil; Class SE or higher
Starting System Recoil Starter
Spark Plug Type NGK CR5HSB
