MT54F RAMMER — OPERATION AND PARTS MANUAL — REV. #8 (01/10/12) — PAGE 33
ROBIN EH-09 ENGINE — CRANKCASE ASSY.
NO PART NO PART NAME QTY. REMARKS
10 2741010121 CRANKCASE CP .................................... 1 ..........INCLUDES ITEMS W/#
20% 2371420203 VALVE GUIDE 2
26 2371600801 STEM SEAL CP 1
30# 0440200070 OIL SEAL 20X32X6 1
40# 0600200140 BALL BEARING 1
50# 0310060020 DOWEL PIN 2
60% 0013906600 STUD 1
61% 0105060200 STUD 1
62% 0105060170 STUD 2
70% 0105060160 STUD 2
75# 0440060010 OIL SEAL 6X10X2.5 1
80 0401140030 PLUG 1
90 0211140020 GASKET 1
150 2741600113 STIFFENER 1
160 0011408250 BOLT & WASHER 2
210 2741100131 MAIN BEARING COVER ......................... 1 ..........INCLUDES ITEMS W/ *
220 * 0440200110 OIL SEAL 20X32X6 1
230 * 0600200140 BALL BEARING 1
250 2304500301 GOVERNOR GEAR CP 1
260 2054190103 GOVERNOR SLEAVE 1
265 0013908500 STUD 4
270 2306360113 OIL GAUGE 1
280 0213160020 GASKET 1
300 0130060200 BOLT & WASHER 9
610 2741300121 CYLINDER HEAD CP ............................. 1 ..........INCLUDES ITEMS W/%
620 2741550103 GASKET, HEAD 1
630 0110080210 FLANGE BOLT 4
680 2741550203 ROCKER COVER 1
690 2741600403 GASKET (ROCKET COVER) 1
700 0310060020 DOWEL PIN 2
710 0011406600 BOLT & WASHER ASSY. 4
727 0566000250 CLAMP 1
820 2741440101 BREATHER PLATE CP 1
825 2741440503 OIL SHELTER PLATE 1
850 2741610103 BREATHER PIPE .................................... 1 ..........BELOW UNIT S/N G-4067
850 2741610203 BREATHER PIPE .................................... 1 ..........UNIT S/N G-4067 & ABOVE
852 0563000020 WIRE BAND 1
860 0011305100 BOLT & WASHER ASSY. 2
ROBIN EH09 ENGINE — CRANKCASE ASSY.
