1. Using a paper towel or cloth, dry off all connections and the DWS housing.
2. Make sure that all connections are tightly secured.
3. Purge any air from the unit.
a. Turn the DWS housing upside down, and then turn on the faucet.
b. Press the right button on the diverter valve to select the filtered water spout. The
water will flow through the DWS and emerge from the smaller opening on the diverter
valve.
c. Allow water to flow through the DWS and filtered water spout for one minute.
d. Press the left button to select the unfiltered water spout, and then turn off the faucet.
4. Turn the DWS right side up and place it on the counter.
5. Make sure that all connections are tightly secured and that there are no leaks.
6. Turn on the faucet and press the right button to selected the filtered water spout.
7. Allow water to flow through the DWS and filtered water spout for approximately
30 minutes. This will flush the filter and charge the carbon.
8. Press the left button to select the unfiltered water spout.
9. Turn off the faucet.
10. Check all connections to make sure that there are no leaks.
1.5: Prepare Your Drinking Water System
2.1: Operating Your Drinking Water System
2. Operation
bypass
lever
unfiltered
water
filtered
water
aerator
6
1.3: Connect the Hose and Diverter Valve to the Faucet (continued)
3. When connected properly, the hose from the diverter valve should lead toward the back of the faucet and sink.
4. The diverter valve features a bypass lever with a button on the left and right sides of the diverter valve. Press the
left button to bypass the DWS and select the unfiltered water spout (larger opening). Turn on your faucet to let
unfiltered water flow out of the diverter valve and to make sure that the diverter valve is properly connected.
5. Turn off the faucet.
1.4: Disconnecting the Hose and Diverter Valve (when replacing hose)
Follow these instructions when you are replacing the hose and diverter valve.
NOTE: Do not forcefully pull the connectors out, this will cause damage to the
housing base. Ensure the system is depressurized before removing fittings.
1. To disconnect the hose, you will need to release the small and large stem
from the housing base (see Fig. A).
a. Push in the collet against the tube stop (center of the fitting). With the collet
held in this position the tubing/stem can be removed. Repeat for both tubes.
2. Proceed with installing new hose to the housing (on previous page). Fig. A
Remove tubing
1. For unfiltered water, press the left button on the diverter valve. Water from the faucet will emerge from the unfiltered
water spout.
2. For filtered water, press the right button on the diverter valve. Water from the faucet will flow through the DWS before
emerging from the filtered water spout.
If you have any questions regarding the installation of your countertop unit, call Multipure:
Customer Service Department
7251 Cathedral Rock Drive, Las Vegas, NV 89128
702.360.8880 phone * 800.622.9206 toll-free * 702.360.8575 fax
email: [email protected] * www.multipure.com
