MK Diamond MK-MANTA I - Manual (Page 2)

1
General Safety Instructions 2
Safety Messages and Symbols 3
Hazard Symbols 3
Damage Prevention Messages 3
Safety Labels 3
Drill Features
Motor 4
Carraige, Column and Base 4
Vacuum Base and Pump 4
Water System 4
Unpacking 5
Assembly
Main Assembly 6
Feed Handle and Meter Box 6
Vacuum Base Gasket 6
Final Assembly 6
Drilling Operations
Electrical Requirements 7
Grounding 7
Extension Cords 7
Securing the Rig 8
Drilling Speeds 9
Drilling Pressure and the Ammeter 9
Water Supply 9
Carraige Rigidity 10
Shear Pin and Clutch Protection 10
Mounting Bits 10
Drilling Procedure 10
Deep Drilling 12
Maintenance
Cleaning 12
Vacuum Base Gasket 12
Trouble Shooting 13
Warranty Information 14
Exploded View & Parts List
Exploded View 15-18
Parts List 19-21
MK Diamond Authorized Service Center Back Cover
How to Order Repair Parts Back Cover
Returned Merchandise Policy Back Cover
MK Diamond’s Manta I Core Drill - Operators Manual
