MK Diamond MK-1280 Rolling Cart User Manual

Page 3

MK-1280 CART ASSEMBLY

Fig. A

Place one nut on each hook bolt.

Thread nut 2/3 up the hook bolt

Fig. C

Place washer on knob and thread

knob on to hook bolt

Fig. B

Place hook bolt through rear hole

of tow bracket

Fig. D

Place Nylok nut on bottom of hook

bolt and tighten. Repeat procedure

for rear lock

Fig. E

Place saw on cart. Place hook bolt

over saw handle. Tighten knob

LOCK ASSEMBLY

Fig. A

To set brake press “on” the

lever on back casters

SETTING BRAKE

NOTE:

The wheels and casters each have a zerk fitting that

needs to be lubricated every 6 months or as needed.
