MK-100
PARTS LIST
Item
Description
Qty
Part#
A
ACCESSORY PACK
N/A
A1
WRENCH, 15/16 CLOSED END
1
134684
A2
CURTAIN, SPLASH
1
160310
A3
BRACKET, SPLASH CURTAIN
1
152571
A4
WINGSCREW, 1/4 - 20 x 1/2
1
151888
A5
WASHER, 1/4 SAE FLAT
1
151915
A6
PUMP, 115V WATER
1
151271
A7
FITTING, PLASTIC, 1/4 FNPT x 1/4 BARB
1
128397
A8
HOSE, VINYL, 1/4 ID
2
132951
A9
CLAMP, FLOW, 1/4 - 1/2
1
154394
A10
OWNER'S MANUAL, WATER PUMP
1
155745
A11
RIP GUIDE
1
159751
A11A
RIP GUIDE ADJ. KNOB
1
159428-1
A12
BLADE, MK-100, 10 x .060 x 5/8
1
154380
A13
OWNER'S MANUAL, MK-100
1
158192
A14
CARTON, ACCESSORY PACK, 101
1
153366
A15
FOAM, ACCESSORY PACK CARTON
1
154022
A16
CARD, MK WARRANTY REGISTRATION
1
155037
A17
LABEL, DO NOT RETURN
1
157063
B
CARTON
166621
B1
ASSEMBLY, CARTON, MK-100
1
160679
B2
COVER, CARTON, MK-100
1
160679-01
B3
TRAY, CARTON, MK-100
1
160679-02
B4
SUPPORT, CORNER, CARTON, MK-100
6
160679-03
B5
INSERT, CARTON, CUTTING HEAD
1
158542-1
B6
INSERT, CARTON, ACCESSORY PACK
1
158542-2
C-E
ASSEMBLY, FRAME
N/A
C1
FRAME, 101
1
153003
C2
PAN, PLASTIC, 101
1
150634
C3
PIN, 3/16 x 3/8 ROLL (NOT SHOWN)
2
151783
C4
PLATE, ADJUSTMENT OBSOLETE (NOT SHOWN)
2
151758
C5
PLUG, RUBBER DRAIN
1
159529
D
POST
N/A
D1
POST, DC, 101, MK RED
1
158438
D2
SHAFT, 10.63" PIVOT, 101
1
153254
D3
SCREW, 3/8 - 16 x 1/2 SCOKET HEAD SET
1
153710
D4
PLATE, SUPPORT
1
155671
D5
SCREW, 3/8 - 16 x 2-1/2
2
156030
D6
WASHER, 3/8 SPLIT LOCK
2
150925
D7
CASTING POST COVER, PLASTIC
1
160157
E
STOP, CUTTING HEAD
157728-MK
E1
STOP, 10" CUTTING HEAD
1
157728
E2
SCREW, 1/4 - 20 x 10 1/4 HEx HEAD CAP
1
157145
E3
WASHER, 1/4 SPLIT LOCK
1
152591
E4
SHEET, CUTTING HEAD STOP INSTRUCTION
1
157728-IS
F-J
ASSEMBLY, 115V CUTTING HEAD, MK-100
1
158225
F
BELT GUARD
1
N/A
F1
BELT GUARD, MK-100
1
158319-00
F2
BRACKET, INNER BELT GUARD
1
158611
F3
SCREW, 1/4 - 20 x 3/4 HEx HEAD CAP
3
152370
F4
SCREW, 1/4 - 20 x 1 HEx HEAD CAP
1
152676
F5
WASHER, 1/4 SPLIT LOCK
4
152591
F6
WASHER, 1/4 SAE FLAT
4
151915
F7
BELT, 260J6 MICRO-V
1
158194
F8
KNOB, 3/8 - 16 x 1.5 MK ADJUSTMENT
1
156770-2
F9
WASHER, 3/8 SAE FLAT
1
150923
