10

K5

Wheel, Roller

2

151799

K6

Screw, 1/4-20 X 1 1/4 Hex Head Cap

2

157145

K7

Washer, 1/4 SAE Flat

2

151915

K8

Nut, 1/4-20 Hex

2

151893

L

Assembly, Splash Curtain

1

155901-MK

L1

Curtain, Splash

1

134841

L2

Bracket, Splash Curtain

1

155901

L3

Washer, 1/4 SAE Flat

1

151915

L4

Wingscrew, 1/4-20 X 1/2

1

151888

M

Table, 470

1

156536

N

Assembly, PES-100 120v Water Pump

1

155987-MK

N1

Pump, Water, PES-100 120v

1

155987

N3

Hose, Vinyl, 1/4 ID

2’

132951

N4

Clamp, Flow, 1/4-1/2

1

154394

N5*

Owner’s Manual, Water Pump

1

155745

*Not shown in exploded view
Rev 12/00
