PREPARE THE HOOD

Unpack hood and check contents.
You should receive:

1 - Hood
1 - 8” Damper / Duct Connector
1 - Glass Visor
1 - Decorative Spacer
1 - Parts Bag containing:

2 - Mounting Brackets
4 - Machine Screws (M4 x 30mm Pan Head)
7 - Mounting Screws (3.9 x 9.5mm Pan Head)
4 - Flat Washers (4 mm diameter)
8 - Screws (4.2 x 15mm Pan Head)

1 - Installation Instructions

8” DAMPER/DUCT CONNECTOR

4 FLAT WASHERS

2 MOUNTING BRACKETS

DECORATIVE SPACER

4 MACHINE SCREWS

(M4 x 30mm PAN HEAD)

8 MOUNTING SCREWS

(4.2 x 15mm PAN HEAD)

7 MOUNTING SCREWS

(3.9 x 9.5mm PAN HEAD)

GLASS VISOR
