4 Looking at or near the Sun will cause irreversable damage to your eye. Do not point this telescope
at or near the Sun. Do not look through the telescope as it is moving.
1. Eyepiece
2.
5 x 24 Viewfinder
3. Viewfinder bracket
4. Viewfinder collimation screws
5. Optical tube assembly
6. Viewfinder bracket attaching nuts
7. Diagonal Mirror thumbscrew
8. Tripod legs
9. Leg brace supports
10. Accessory tray
11. Alt-azimuth mount
12. Optical tube mounting plate
13. Focusing knob
14. Optical-tube-to-mount locking knob
15. Diagonal mirror
16. Objective lens and lens cell (inside tube)
17. Eyepiece holder and thumbscrew
18. Tripod leg lock latch
19. Adjustable sliding leg extension
20. Dew shield/lens shade
21. Front lens cap(not shown)
B
C D
F
e
1*
g
1)
J
I
H
1^
1$
1@
1!
1&
1%
2)
2!
1(
Fig. 1: Meade 50AZ-P 2” Alt-azimuth Refracting Telescope
1#
