Refracting Telescopes use a large objective lens as their primary light-collecting element. Meade refrac-
tors, in all models and apertures, include achromatic (2-element) objective lenses in order to reduce or
virtually eliminate the false color (chromatic aberration) that results in the telescopic image when light
passes through a lens.
Reflecting Telescopes use a concave primary mirror to collect light and form an image. In the Newtonian
type of reflector, light is reflected by a small, flat secondary mirror to the side of the main tube for obser-
vation of the image.

In the refracting telescope, light is collected by a 2-element objective lens and brought to a
focus at F.

In contrast, the reflecting telescope uses a concave mirror for this
purpose.

F

Eyepiece

2-Element

Objective Lens

F

Eyepiece

Concave

Mirror

Secondary

Mirror

Refracting Telescope

Reflecting Telescope

WARNING!

Never use a Meade

®

DS2000

Telescope to look at the Sun!

Looking at or near the Sun will cause instant and irreversible
damage to your eye. Eye damage is often
painless, so there is no warning to the observer that damage has
occurred until it is too late. Do not point the
telescope at or near the Sun. Do not look through the telescope

or SmartFinder™ as it is moving. Children should always have
adult supervision while observing.
