6
1
2
5
11
10
6
16
20
13
15
7
3
22
Fig. 1: DS-2000 Series Telescope.
Features of the DS-2000 Series telescopes
are virtually identical. Certain features of
your telescope may look different than, or
be positioned slightly different than the
one pictured here, but the functionality of
the features is the same.
Fig. 1c (Inset): Computer Control Panel. (A)
Handbox port; (B) Power indicator light, (C)
ON switch; (D) Auxiliary port.
A B C D
8
12
14
19
18
21
23
24
25
E F
Fig. 1b (Inset): (E) Altitude
Setting Circle; (F) Altitude Lock. Fig. 1d (Inset):
Compass/Bubble Level.
4
26
17
1. Focus Knob
2. Eyepiece Holder
3. 90° Diagonal Prism
(refractors only)
4. Eyepiece Holder
Thumbscrew
5. Eyepiece
6. Focus Lock Knob
7. Red Dot Viewfinder/Bracket
8. Red Dot Viewfinder
Alignment Screws
9. Compass/Bubble Level
10. Altitude Setting Circle
and Lock
11. Dew Shield
12. Dust Cap
13. Optical Tube
14. Cradle Ring Lock Knob
15. Cradle Ring
16. Mounting Arm and Shaft
17. Computer Control Panel
18. Accessory Tray
Attachment Bolts
19. Accessory Tray
20. Tripod Lock Knob
21. Tripod Leg Locks
22. Tripod Legs
23. Tripod Base
24. Azimuth Setting Circle
25. Battery Compartment
26. Base Lock Knob
27. Inner Support Struts
27
(not visible)
9
