A
ssembly
5
Lower
Body Base
Your Lift-Off Steam Mop assembles
quickly and easily. The only thing
you will need for assembly is a
Phillips head screwdriver.
Your Lift-Off Steam Mop is packaged
with the following items:
Handle Assembly
Lower Body base
Detachable Steam Pod with water
purification
Maneuverable Swivel Head
Removable Water Tank
1 small Phillips Head Screw taped
to the handle
2 Deluxe Mop Pads
1. Attach lower body base to
maneuverable swivel head.
2. Secure maneuverable swivel head
with small Phillips head screw. Tighten
until secure.
3. Slide handle assembly down into
lower body base until it will go no
further. Secure the handle by turning
the knob until tight
Lift-Off Steam Mop assembly is now complete.
Handle Assembly
Lower Body
Removable Water Tank
small Screw
Maneuverable
Swivel Head
2 Deluxe Mop Pads
2 1
3
