Mayline Bracket Leg Kit User Manual
Mayline Furniture
PRINTED IN USA
1
BRACKET LEG KIT EZBLK
6/1 2
I772
Ped side
1 . Attach the leg to the outside corner opposite where the ped will be located. Be sure to face the
gusset to the inside.
Gusset
A
C
B
ITEM QTY DESCRIPTION
A
1 2 #1 2 X 1 .00 PHILLIPS PAN HEAD WOOD SCREW
B
2
#1 0 X 3/4 PHILLIPS PAN HEAD PARTICLE BOARD SCREW
C
2 #1 0 FLAT WASHER
