FORCECUT 62i
10
Assembly of Consumables for the 60AMP Torch
Head
Assemble the consumables as pictured above, and described below.
1. Screw on the electrode.
2. Place the copper tip on the ring, ensuring that is seated flat.
3. Secure all parts into place by turning the grey shield cup clockwise until it is snug. Do not
over tighten.
The torch consumables are now successfully assembled.
Basic Operation
1. Ensure that all cables are connected to the machine.
2. Ensure that the machine’s OFF/ON switch is set to OFF, and plug the machine into the
electrical outlet.
3. Connect the air compressor supply line to the air input side on the unit.
4. Turn the ON/OFF switch to ON. The cooling fans should operate and the ON indicator LED
or power switch (if applicable) should illuminate.
5. Clean the contact point on the work piece to ensure a good electrical connection. Ensure that
no rust of paint is present that could create an open circuit.
6. Connect the ground clamp to the work piece to be cut.
7. Connect the torch to the unit properly.
8. With the pilot arc knob connected, you should get a full continuous arc when the trigger on
the torch is pressed.
9. Depress the button on your torch to start the arc and begin cutting.
10. You can test the air to insure that is it properly flowing by selecting Gas (Air) Test. Air will
pass through the torch.
11. If necessary remove slag from the under part of the cut using a grinder or chisel.
