PROMTS 200i
9
Main Unit Knob/Button/Function:
1. Process Selector: Press to select MIG, TIG or STICK.
2. 2T or 4T: Button for selecting 2T or 4T
3. Welding Amps While Welding/ Set Amps Before Welding
4. Wire Speed Indicator
5. Amp Indicator: When the light is on it indicates that the amps are being displayed.
6. Voltage Display: View and set amps.
7. Voltage Indicator
8. Arc Force:
9. ON Led is lit when the machine is on
10. Fault Indicator indicates when the machine setting has too much voltage or too little
voltage. Also indicates if the duty cycle has been reached
11. Down Slope
12. MIG Gun Connector
13. Negative Connector
14. Trigger Connector
15. Positive Connector
16. Wire Speed Knob
17. Voltage (MIG) / Downslope (TIG) / Arc Force (STICK) MIG
18. Wave Form Knob
19. TIG Torch Gas Line Connector
20. Power Switch
21. Gas Line to CO2 Mix or 100% Argon Tank
22. Power Cord
23. Remote Switch
24. Spool Gun Switch
25. Burn Back Knob
26. Slow Feed Knob
