14
SPeciFicaTionS
Frequency
response
process mode Program controlled
bypass mode 10Hz to 50kHz +/-0.5dBu, -10dBu input
Thd
process mode less than 0.025% at -10dBu input, 20-20kHz
bypass mode less than 0.002% at -l0dBu input, 20-20kHz
Maximum output +18dBu (may vary due to control settings)
input impedance 47k Ohms, unbalanced 1/4” phone jack or RCA jack
output impedance 1k Ohms, unbalanced 1/4” phone jack or RCA jack
Sensitivity -45dBu for maximum process
Maximum Process +12dBu boost at 5kHz, -10dBu input
Lo contour +12dBu boost at 50Hz, -10dBu input
Power
requirements
U.S., Canada
and Japan
models 100-120VAC, 50/60Hz, 8 WATTS
220-240
models 220-240VAC, 50/60Hz, 8 WATTS
Fuse For all models, replace with 250VAC, .2A slowblow type
fuse.
dimensions 19”(W) x 5.5”(D) x 1.7”(H)
Shipping Weight 6.5 lbs.
* 0dBu = 0.775mVrms
Note: Due to continuing product improvement, specifications and design are subject to change without notice.
