Display parts, controls and connectors
37
When the display is shipped, the display height mechanism is
locked to prevent damage during shipping. To unlock the
mechanism and adjust the display height, pull out the red hook
while pushing down the display panel. Then slowly release the
display panel.
Connectors
Figure 3: Connectors rear
R
L
2
3
4
5
6
1
7
8
8
