Installation 13
There is 3% ~ 5% tolerance among these numbers due to optical component limits.
* 1m = 3.28 feet, 1 feet = 0.305m, 1m = 100cm, 1 feet = 12 inches
Connecting to Various Equipment
HDTV Equipment
The projector is capable of displaying various High Definition TV display modes. Some of
these sources are:
Most of these sources will provide an analog component video output, a standard VGA out-
put, or a YP
b P r (default) format.
The projector is capable of accepting HDTV data through a Component Video connector.
Use a Component Video cable that came with your projector to display these images.
The following standards are supported in the HDTV function:
PB7110 (SVGA) screen size chart (16:9 aspect ratio)
Distance
from screen Diagonal measurement Distance from
screen Diagonal measurement
Minimum
zoom Maximum
zoom Minimum
zoom Maximum
zoom
feet inches feet inches feet inches meters cm meters cm meters cm
4 48 1.80 21.6 2.20 26.4 1 100 0.45 45.1 0.55 55.0
6 72 2.70 32.4 4.20 50.4 1.5 150 0.68 67.6 0.82 82.5
8 96 3.61 433 5.60 67.2 2 200 0.90 90.1 1.10 110.0
10 120 4.51 54.1 7.00 84.0 2.5 250 1.13 112.7 1.37 137.5
12 144 5.41 64.9 8.40 100.8 3 300 1.35 135.2 1.65 164.9
14 168 6.31 75.7 9.80 117.6 3.5 350 1.58 157.7 1.92 192.4
16 192 7.21 86.5 11.20 134.4 4 400 1.80 180.3 2.20 219.9
18 216 8.11 97.3 12.60 151.2 4.5 450 2.03 202.8 2.47 247.4
20 240 9.01 108.2 14.00 167.9 5 500 2.25 225.3 2.75 274.9
22 264 9.91 119.0 15.39 184.7 5.5 550 2.48 247.9 3.02 302.4
24 288 10.82 129.8 16.79 201.5 6 600 2.70 270.4 3.30 329.9
26 312 11.72 140.6 18.19 218.3 6.5 650 2.93 292.9 3.57 357.4
28 336 12.62 151.4 19.59 235.1 7 700 3.15 315.5 3.85 384.9
30 360 13.52 162.2 20.99 251.9 7.5 750 3.38 338.0 4.12 412.4
32 384 14.42 173.1 22.39 268.7 8 800 3.61 360.5 4.40 439.8
• Digital-VHS (D-VHS) player • DVD player
• Satellite Dish HDTV receiver • Digtial TV tuners
• 480i • 480p
• 720p • 1080i
