Product Diagrams
Front Drawing
1 .Tap Selection Switch
2. Coaxial Driver Assembly
3. Grille Retention Slot
4. Bass Tuning Vent (x2)
5. Perforated Steel Grille
Rear Drawing
1 . Snap-Lock Input Connector
2. Suspension Points (x3)
3. Safety Cable Suspension Point
Package Contents
(1) Pendant Speaker
(1) Installation and Use Manual
(1) Snap-Lock Input Connector
(1) Quick-Snap Clip
(2) Cable Kits
(3) Suspension Cables with Forged Eye Bolts
(3) Nuts (maybe installed onto eyebolts)
Front Drawing
(grille partially shown)
Rear Drawing
1
