Billion Electric Company BiPAC 7404V Series - Manual (Page 136)

VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
Chapter 4: Configuration
135
Edit DMZ Host
The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address
as the DMZ Host, all incoming packets will be checked by the Firewall and NAT algorithms then passed to
the DMZ host, when a packet received does not use a port number used by any other Virtual Server
entries.
Cautious: This Local computer exposing to the Internet may face varies of security risks.
Disabled: As set in default setting, it disables the DMZ function.
Enabled: It activates your DMZ function.
Internal IP Address: Give a static IP address to the DMZ Host when Enabled radio button is checked.
Be aware that this IP will be exposed to the WAN/Internet.
List all existing PCs connecting to the network. You may assign a PC with IP address and
MAC from this list.
Select the Apply button to apply your changes.
